SPECIFICATIONS 260P
External dimensions (mm) - L: 6670, W: 2100, H: 2800
Internal dimensions (mm) - L: 6000. W: 2000, H: 2200
GVWR (kg) - 2700
Payload capacity (kg) - 1500
Breakable - Yes
Overrun brake - Yes, AL-KO
Jockey wheels - Yes, AL-KO
Drawbar - V-drawbar, not removable
Frame - Hot dip galvanised steel
Support legs - 4x500 kg AL-KO
Wheels - 4, 195/50R13C 104/102N
Lighting - LED road lights in accordance with Road Code
Walls and roof - 550 mm thick sandwich panels made of glass laminate with gelcoat surface for maximum UV and weather resistance
Colour - White
Number of sales flap/ dimensions (mm) - 1 with gas struts, L: 2600, H: 1400
Aluminium window - N/A
Entrance door/ dimensions (mm) - 1, L: 800, H: 1900
Input door - Key Lock
Floor - Colour: Grey, soft sanded with wear-resistant anti- slip coating
STANDERT EQUIPMENT
ALH 260WSN
Electrical installation: 230V, eight single sockets, LED interior lighting
Sanitary module (stainless-steel):
Double sinks with cabinet L: 800mm, W: 550mm, H:900mm, 2x20L tanks, electric instant water heater
Stainless-steel exhaust hood, dimensions (mm):
With one big fan (1300m3/hour), L: 1500, W: 800
Stainless-steel protective backsplash:
Placed under exhaust hood
Stainless-steel worktop with sliding door and shlef (mm):
L:1500, W: 550, H: 900
Stainless-steel worktop with sliding door and shlef (mm):
L:1500, W: 550, H: 900
Stainless-steel worktop with shelf (mm):
L:1500, W: 550, H: 900
Stainless-steel worktop without shelves and door (mm):
L:1500, W: 550, H: 900
ADDITIONAL EQUIPMENT
Electrical installation 230V
Electrical installation 380V
Flat floor (trailer without wheel arches)
Extra width 20 cm
Additional flap with aluminum window L: 1600 mm, H: 1100 mm
Exhaust hood of different sizes
Removable drawbar
Plywood cabinet, shelves, worktops of different types and sizes
Stainless-steel cabinet, shelves, worktops of different types and sizes
